  • SKS Welding Systems FB5 field bus

    For integration with fieldbus:

    Fieldbus solution for all common industrial robots, e. g. with Profibus DP and DeviceNet

  • SKS Welding Systems FB5 field bus

    For integration with fieldbus:

    Fieldbus solution for all common industrial robots, e. g. with Profibus DP and DeviceNet

Interface FB5:

Fieldbus integration

Fieldbus systems exchange signals via serial communication. The fieldbus master (in most cases the robot controller or higher-level plant control system) collects and processes the signals of the connected fieldbus slaves (including, among others, the welding machine). Common fieldbus systems are, for example, Interbus-S, Profibus DP or DeviceNet. The fieldbus interface FB5 translates the fieldbus signals for the welding machine and uses a standardized protocol. This ensures that the signals are always positioned in the same place within the fieldbus – independently from the fieldbus type. And it makes the preparation of the robot and/or the plant control system easier.

The FB5 fieldbus module is integrated into the system with the L-700 standard trip line. The “external” version has bores for flexible mounting in the welding cell.

Fieldbus FB5

  • Benefits - Fieldbus

    Benefits - Fieldbus

    • Support of common fieldbus systems (Interbus, Profibus DP, DeviceNet)
    • Open architecture for further fieldbus systems
    • Signals are independent from the fieldbus type as a standardized protocol is used
    • Convenient set-up of the plant control system and/or robot
    • Other fieldbus types on request

Fieldbus FB5 Features

Performance Characteristics:

supports DeviceNet / Profibus / Interbus (further fieldbus types on request)

Power Supply:

internal via SPW / optional: external with 24 VDC

Weight:

0.80 kg

Dimensions (l / w / h):

280 / 110 / 70
